IF-100C
POWEAM MEDICAL
Blood Warmer IF-100C
Feature:
l Multiple Temperature Control
l Different Kinds Heating Profile
l High Accuracy
Technical Parameters
l Temperature Setting: 32.0°℃-42.0°℃ or 86.9°F～107.6°F
l Temperature Accuracy: ≤土1℃ or ≤土1.8°F
l Increment: 0.1℃ or 0.2° F
l Unit: Celsius &Fahrenheit
l Warming Time: ≤4min
l overheat Protection: hardware and software protection 50±5°C
l Alarm: Overheat, low temperature, system error,door open，warming up alarm.
l Blood and IV Sets:diameter:3.5-7.0mm PVC blood tube or IV tubes, different heating profiles are available.
l 72*72mm LCD Display
l Heating Way: dry silicon heating profile
l Mute time: 2mins
l Heating time: 0-99h59min
Installation | IV knob or hanger.(Hanger is optional) |
AC Power | 100-240V, 50/60Hz, 0.3-0.7A |
Power consumption | 60VA |
Working Environment | Temperature: +5°C-+30°C, Humidity:20%-80% |
Transport and Storage | Temperature: -20°C-+55°C, Humidity: 10%-93% |
Protection against Liquid | IPX4 |
Working Mode | continuous heating |
Size | 155*110*170mm |
Weight | 1.2kg |
