WHYM201
Poweam
Display: 7" TFT LCD 800X480 pixels
Detection method : Absorbance
Microplate types: 96-well plate
Measuring system:8-Channel optical ststem
Reading speed: 5s single wavelength
Light source: Based on mono-LED illumination. Life for more than 100,000 hours
405nm,450nm:492nm,630nm,2 free positions for additional filters
Large memory:1200 times of testing for 96 well results
Reading range:0.001-3.500Abs
Measurement range: 0.001-2.500Abs
Wavelength accuracy: <2nm
Repeatability: <1%
Photometric accuracy: <1% or ± 0.001Abs
Linearity: <2.0%
Stability: <0.005Abs/10min
Shaking:linear shaking; Low,medium,high
Input:keyboard,touch screen is optional
Power supply:AC220V/110±10%,50/60Hz
Operating environment: Temperature:10°C~35°C
Humidity:15~85%
Display | 7" TFT LCD 800X480 pixelsDetection method Absorbance |
| Microplate types | 96-well plate |
| Measuring system | 8-Channel optical ststem |
| Reading speed | 5s single wavelength |
| Light source | Based on mono-LED illumination. Life for more than 100,000 hours |
| 405nm,450nm | 492nm,630nm,2 free positions for additional filters |
| Large memory | 1200 times of testing for 96 well results |
| Reading range | 0.001-3.500Abs |
| Measurement range | 0.001-2.500Abs |
| Photometric accuracy | <1% or ± 0.001Abs |
| Wavelength accuracy | <2nm |
| Repeatability | <1% |
| Stability | <0.005Abs/10min |
| Linearity | <2.0% |
| Shaking | linear shaking; Low,medium,high |
| Input | keyboard,touch screen is optional |
| Power supply | AC220V/110±10%,50/60Hz |
| Operating environment | Temperature 10°C~35°C |
| Humidity 15~85% |
Below is our microplate washer and microplate reader picture before packing:
Below is our OEM products picture before print customer logo:
