c-arm 1200c
Poweam
PRODUCT DESCRIPTION
Product Usage
C-arm 1200B is a HIGH FREQUENCY MOBILE DIGITAL C-ARM SYSTEM
Orthopaedics: Osteopathy, Diaplasis, Nailing
Surgery: orthopedic, removing foreign body, implanting pace maker, partial radiography, local photography, Assist endoscopy and other work.
More
Configuration
1, | New (with electric auxiliary support arm) C-arm Frame |
2, | High-frequency high-voltage X-ray generator and high-frequency inverter power supply |
3, | 24 inch ordinary LCD, resolution 1920x1200 |
4, | 19 inch ordinary LCD, resolution 1280 * 1024 |
5, | 9 Inch three field image intensifier |
6. | Megapixel ultra-low illumination digital camera, Camera pixel matrix description: 1024x1024 |
7, | Digital acquisition and processing workstation |
8, | Dense grid |
9, | Electric adjustable beam collimator |
10. | handheld controller |
11. | Laser cross positioner |
12, | Digital work station |
Features
1. High quality combined high-frequency and high-voltage X-ray generator, greatly reducing the X-ray exposure;
2. It has the function of automatic tracking of perspective kV and Ma, which makes the image brightness and clarity in the best state automatically;
3. The real-time and continuous pulse perspective mode has small ray dose, but the image is clearer, which can meet the needs of high-precision and difficult minimally invasive surgery, and can effectively protect medical care Safety of personnel and patients;
4. The host operation interface of the human graphical LCD touch screen is adopted to make the operation more intelligent and convenient; 5. The design of the hand-held controller makes the operation of the instrument more convenient;
6. The 9-inch three field image intensifier is used, with stable and reliable quality and good image definition; 7. The megapixel ultra-low illumination digital camera is used, with clearer image;
8. Standard workstation and advanced image software processing technology make the image clearer, convenient for doctors' operation and diagnosis, standard DICOM interface and easy to link with hospital information system;
9. Electric auxiliary support arm design, safer use;
10. New frame design, small and beautiful appearance;
11. Realize the function of digital photographing, make the photographing operation more convenient and the image digital processing more efficient.
Product Specification
▶ Monoblock
● Focus:0.6/1.8
● Anode capacity：35.5kJ（47kHu）
● Tube Heat capacity：650kJ（867kHu）
● Power output：5kW
● Inverter Frequency：≥40kHz
● Continous Fluoroscopy (Manual/ automatic)
○ Tube voltage：40kV～120kV
○ Tube current：0.3mA～4mA
○ Automatic brightness tracking function
● Pulse fluoroscopy
○ Tube voltage：40kV～120kV
○ Tube current：0.3mA～30mA
○ Pulse frequency: intelligent control reduces the radiation dose, improves the quality of single frame image and improves the continuous working time
● Radiography mode
○ Radiography：40kV～120kV
○ Radiography tube current：25mA～100mA
○ Radiography mAs：1.0mAs～180mAs
● Beam limiter: Electric iris + linear symmetrical rotatable
● Working environment conditions
○ Environment temperature ：10°C—40°C
○ Relative humidity：30%—75%
○ Atmospheric pressure：700hpa—1060hpa
● Operating power condition
○ Power supply voltage and phase number: single-phase 220V ± 22V
○ Power frequency：50Hz±1Hz
○ Internal resistance of power supply: no more than 1 Ω
▶ Imaging system
● image intensifier: 9 ″ three field e5764sd-p3, center resolution 4.8lp/mm
● camera: ultra-low illumination, one million pixel black and white progressive scanning
● LCD: 24 inch ordinary LCD, resolution 1920x1200, working frequency: 60Hz
● image acquisition and processing workstation
○ Registration: Registration preservation, medical record query, worklist
○ Acquisition: start acquisition, prepare recording, reset, horizontal mirror, vertical mirror, window adjustment, magnifying glass, negative image, edge
Edge enhancement, recursive noise reduction
○ Processing: four windows, nine windows, sharpening, horizontal mirror, vertical mirror, text annotation, length measurement
○ Report: save, preview, expert template
○ DICOM function: DICOM browsing, network service
● image definition index
○ Gray level: ≥ 11
○ Line pair resolution: ≥ 2.0lp/mm
Clinical images
▶ Mechanical part
● forward and backward movement: 200mm
● rotation around horizontal axis: ± 180 °
● rotation around vertical axis: ± 15 °
● focal screen distance: 1000mm
● C-arm opening: 760mm
● arc depth of C arm: 670mm
● sliding along the track: 120 ° (+ 90 ° ～ - 30 °)
● electric lifting of column: 400mm
● guide wheel and main wheel: the guide wheel can rotate in any direction, and the main wheel can rotate ± 90 °
● with electric auxiliary support arm
● full balance: when the mechanical movement of the equipment is unlocked, the C-arm is balanced at any position and angle without sliding
● light thrust
