Radiographic Medial X-ray Film Processor

Feature:

Widely applicability medical diagnosis and experiment fields.

Microcomputer control system:LCD panel and computer panel.

Unique design for channel,prevent each channel to be crossed and improve the cyclic utilization of the liquid effectively.

Anti-oxidation and anti-crystallization configuration.

High-density roller guarantee transporting film safely and easy to clean.

High speed on rinsing.It can develop 220 sheets/h,meet requirements for all hospitals .

High standard and high economic, control the temperature accurately, the mistake of temperature is less than 0.3degree. the consumption of water is reducing when it standby .

Technical Parameters

Type desktop /Console model

Rinse width: 4"*4"-14"*17"

Developing capacity:80 films/h (14”*17”);

145 films/h (10”*12”)

Process time: 105/135/165secs

Develop time: 25/35/45sec

Film feed mode:U-slot

Film sensing mode:micro switch

Develop temperature: 28 -37℃(±0.3℃ )

Dryer temperature: 40-65℃

Channel volumD/F/W: 5.2litres

Washing Control: Water 2~8L/min when rinsh

Replenishment: Auto. /manual 20~200ml/for 0.5s. Q. M

Water developing control mode: solenoid vavle control

Anti-oxidation function:60mins interval

Anti-crystallization function: 20mins interval
